Hydraulic Flow and Pressure Checklist

What to verify before selecting a shear, pulverizer, auger, compactor or rotating attachment.

Hydraulic Flow and Pressure Checklist

Hydraulic attachments must be matched to the usable circuit, not just the carrier size. Confirm the machine settings, plumbing and control functions before finalizing motors, cylinders and valves.

01

Verify the available circuit

Use the carrier manual or a measured service report where possible. Record continuous and maximum values separately so the attachment is not selected around a short-duration peak.

  • Usable flow range
  • Working and relief pressure
  • Return-line arrangement
  • Case drain requirement
02

List every required function

Opening, closing, rotation, tilt and auxiliary movements may require separate controls or a switching valve. The operator interface should be understood before hoses are specified.

  • Primary working function
  • Continuous or intermittent rotation
  • Open/close and rotate simultaneously
  • Electrical control or foot-pedal availability
03

Confirm installation details

Hose length, port size, couplers and protection affect installation and serviceability. Include the preferred connection standard and photos of the boom plumbing.

  • Port and coupler standard
  • Hose routing and protection
  • Required hose length
  • Commissioning and pressure-setting plan

Next step

TURN THE GUIDE INTO A CONFIGURATION ENQUIRY.

Add the carrier make, model and operating weight, interface dimensions, material and required task to your brief. After your enquiry is successfully stored, PINSHENG checks compatibility and prepares a quote.

What happens after you submit

Use the enquiry form to include the carrier make, model and operating weight; pin diameter, pin centers and dipper width; working material, destination country and target date. For hydraulic attachments, add flow and pressure.

After your enquiry is successfully stored, the form shows “Enquiry received”. PINSHENG will review the machine, interface, material and hydraulic details before preparing a quote.

If the form reports an error, check the required fields and try again. Opening WhatsApp or email only prepares a message — send it in your chosen app.
